System height (m) 1.15 System width (cm) 34

Working with:
W1W5

Containment levels:
H1T1T3

Technical data

.

Grounding, Type Paved surface, asphalt, construction, median crossing
Use type Temporary, Permanent
Containment level T1 T3 H1
Working width W1 W2 W5
norm. Working width 0.4 m 0.7 m 1.4 m
Dyn. Deflection 0.10 m 0.40 m 1.01 m
ASI A A B
end anchorage no no yes
Test no. light vehicle BASt 2014 7E 58 BASt 2014 7E 58 BASt 2015 7E 52
Test no. heavy vehicle BASt 2014 7E 58 BASt 2015 7E 52
Test length 132 m 132 m 132 m
System length 12 m
System height 1.15 m
System width 34 cm
Planning width 16 cm
Area of operation A B D E

Detention level T1 T3 H1
Working width W1 W2 W5
ASI A A B
Dyn. deflection 0.10 0.4 1.0
